HSS - AX4-N


TECHNICAL SPECIFICATION OF DRAW TEXTURISING MACHINE MODEL HSS - AX4-N



1 Equipment Draw Texturising Machine
Himson Super Set - AX4 – N
2 Main Specifications
  a Products Polyester 30 De to 300 De
b No of Positions 312
c Mechanical Speed 540 to 1100 mpm
d Draw Ratio Optional setting values within the above speed range
e Direction of twist All “S” All “Z” or alternate S and Z
f Heating Device Double Heater Type
g Dimensions (LxWxH) 21.128 x 6.43 x 3.76 meters (width over box creel)
3   Utility
  a Electric Power Rated input voltage A/C 415 V ± 10%
Frequency 50 HZ ± 0.5 HZ
Supply 3 Wires + Earth + Ground
Connected Power
Motors – 88 KW with NFR
Heaters – 66.3 KW
Total - 154.3 KW
b Compressed Air Needed only while using inter lacing jets Qty and quality of supply as per jet selection.
c Air Conditioning Room Temperature 26°C ± 2 °C
  (Only recommendation) Relative Humidity 60 – 65%
4 Specifications in Detail
  a 1st Heater 26 Blocks of 12 positions each along with Suction
threading system (TELEPHONE)
  Heating System Vapour Phase – High efficiency System
  Rate Output 1.7KW / Block
  Temperature Range 160°C to 250°C
  Length of Heater 1.6 meters
  2nd Heater 13 Blocks of 24 Positions each
  Heater System Vapour phase – High efficiency system
  Rated Out put 1.7KW / Block
a Temperature Range 140°C to 230°C
b Length of Heater 1.4 meters
c Cooling Zone 312 sets / machine
d Cooling Zone length 1.25 meters
  Type of cooling Device Natural air cooled track Nitrogensed and Ultra
finished yarn contact area.
d
 Twisting Units 312 Sets / Machine
  Type Tri axial spindle – optimized geometry
  Working disc Polyurethane 54.5 Ø – 9mm thick
  Disc Combination 1 – 4 – 1 Standard Supply Expandable 1 -5 – 1
Guide Disc Solid Ceramic
Driving System Tangential Belts
e
 Feed System 312 sets / Machine
  1. No of feeds

1 FR – Nip Roller

(optional – Apron System)
2 FR – Apron System
NFR – Nip Roller

(only for AX4 N)
3 FR – Nip Roller
  2. Apron System Apron Carriers For precise yarn control
  3. Yarn traverse over Nip 1 FR – 15 mm (8mm for apron system)
2 FR – 8 mm
NFR – 12 mm
3 FR – 12 mm
f
 Take Up System 312 sets / Machine
1. Cradle mandrill less cradle
2. Tailing Device R H Slide
3. Bi- conical Angle 3°-9°-18°
4. Traverse Length 250 mm
5. Package dia 250 mm
6. Max. Package weight 7 Kgs
  7. Take up tube 290mm long 69 mm Ø or 57mm Ø
  8. Traverse System oil bath lubricated, 4 position units with optimized cam profile
  9. Traverse Speed upto 600 double strokes per minute.
  10. Package build device Revised axial disturber unit inverter Controlled programmable motor unit.
  Oiling System 1 set / Machine
  1. Type Lick roller system with grooved rollers
  2. Oil Feed Gravity feed with oil level control tank
  3. Roller Speed variable rpm 1 to 20
h
 Fume Exhaust 1 Set / Machine
1. Yarn Suction 1 Set / machine
2. Yarn Cutters 26 sets (12 cutters each)
Type Cut & hold type
  3. Detectors

26 sets (12 each)
Type Non contact type
i
 Drivers 1 Set
  1. Drive System Motors for individual feed – speed control by inverters
  2. Capacity of Motor
1 FR 3.7 KW x 2 7.4KW
2 FR 11.0 KWx1 11.0KW
NFR 7.5 KW x 1 7.5KW
3 FR 7.5 KW x 1 7.5KW
WR 11.0 KW x 1 11.0KW
TU 11.0 KW x 2 22.0KW
TCR 7.5 KW x 1 7.5KW
Suction 7.5 KW x 1 7.5KW
Fume 2.2KW x 2 4.4KW
Other 2.2 KW 2.2KW
TOTAL   88KW
  3.Heater
  Primary 1.7 KW x 26 = 44.2 KW
  Secondary 1.7 KW x 13 = 22.1 KW
    Total 66.3 KW
  n. Creel Stand 1 set – Box type creel
4 High Rotary Creel optional
  o. Electric Control System 1 set / Machine

Optional:

  1. This machine can be also supplied in 336 spindles, 360 spindles (split type)
  2. Co – mingling attachment- including extra set of detectors, guide, & bracket.
  3. Manifolds – Air jets manifolds at intermediate position
  4. Apron – at input / output in lieu of Nip Roller
  5. Heater Option

  6. a) Length          1.6 meters
        Type            Open / Close
    b) Length          2 meters
        Type            Open / close
